BMX MEYBO Patron Pro 22.5" Bordeaux 2025

Manufacturer ref.: VEME2544
The BMX MEYBO Patron Pro 22.5" 2025 is a premium complete BMX Race bike developed for riders seeking maximum performance on the track. This... Read more
Regular price 28 101,00 SEK
Regular price Sale price 28 101,00 SEK
View full details

Description

The BMX MEYBO Patron Pro 22.5" 2025 is a premium complete BMX Race bike developed for riders seeking maximum performance on the track. This version features a Meybo HSX Alu frame offering an excellent compromise between stiffness, lightness and efficiency. Combined with an SD Carbon V2 Pro Tapered fork, this BMX ensures optimal precision during acceleration and riding phases.

Designed for competition, the Patron 2025 integrates components selected for their dynamism, reliability and ability to withstand the demands of modern BMX Race. The Shimano MT501 hydraulic braking system provides powerful and progressive control, while the wheels fitted with SD Carbon M58 V2 rims enhance the bike's responsiveness and reactivity.

The Pro 22.5" configuration is suited to riders seeking a balanced geometry with a 22.5-inch Top Tube, excellent stability and an efficient position for both gate starts and technical sequences. The SD Ace Pro and SD Ace HSX hubs guarantee rapid power transfer thanks to the 180 engagement points of the rear hub.

With its high-end equipment such as the SD Pro Hollow crankset, Tioga Fastr-X tyres and KMC K1 chain, the MEYBO Patron Pro 22.5" 2025 is ready to tackle the most demanding tracks. This complete BMX combines explosiveness, precision and robustness for experienced riders seeking a high-performing machine directly oriented towards competition.

Ref: 15995238220156

Technical information

Model: MEYBO Patron 2025
Size: Pro 22.5"
Rider level: Experienced
Recommended size: 5'11" and above
Material: Meybo HSX Aluminium
Use: BMX Race competition
Top tube: 22.5"
Down tube: 22.99"
Chainstay length: 15.35"
Head angle: 74°
Seat tube angle: 71°
Seat tube diameter: 27.2 mm
Rear dropouts: 15 mm
Bottom bracket shell: BB30
Compatibility: disc brake only

Steering / Cockpit
Fork: SD Carbon V2 Pro Tapered
Front axle: 20 mm
Headset: FSA sealed bearings Full Integrated
Headset standard: 1-1/8" - 1.5"
Handlebar: SD Cr-Mo 8"
Stem: SD CNC machined 50 mm
Grips: SD Lock-On 130 mm

Braking
Calliper / system: Shimano MT501 hydraulic
Type: Disc brake

Wheels
Front hub: SD Ace Pro
Drilling: 36 holes
Front axle: 20 mm
Rear hub: SD Ace HSX
Rear axle: 15 mm
Rear engagement: 180 points
Wheels: SD Carbon M58 V2
Rim dimensions: 20 x 1.75"
Rim width: 25 mm

Tyres
Tyres: Tioga Fastr-X
Dimensions: 20 x 1.75"

Drivetrain
Crankset: SD Pro Hollow
Type: 4-bolt
Crank arm length: 175 mm
Bottom bracket: SD BB30 24 mm Euro/BSA
Chainring: SD CNC Aluminium 6061
Number of teeth: 44T
Sprocket: 16T
Chain: KMC K1 3/32 Silver/Black
Chain tensioners: Integrated

Saddle: Box Two Pro
Seatpost diameter: 27.2 mm
Saddle clamp: SD QR
Clamp diameter: 31.8 mm

Weight: 8.95 kg
